D8

Our new D8 (Direct 8) coaxial studio monitors are the next step in the D Series line.  Geared for the recording professional, the D8 delivers the crystal clear mid-range detail first presented by the D5s but with higher SPL and  and much bigger bass response.  Focused attention was paid to the development details to ensure that they deliver professional sonic performance. These studio monitors feature an expensive coaxially designed transducer with an 8″ woofer and a 1″ silk tweeter. The frequency response is 44hz to 20khz. The D8s cutting edge digital amplifier provides extremely low distortion with plenty of punch. The internal DSP allows for intricate pin-point accurate adjustments. The D8 was designed specifically to deliver a much bigger sound while maintaining the extreme level of detail that the D5 has been proven to provide.

The D8 studio monitors have pro features;  balanced XLR and balanced/unbalanced TRS inputs;  a calibrated stepped level sensitivity control; a 3 alternate voice boundary selection switch; an all wood cabinet, including a wood front baffle for optimum performance; a fully extended 2.5″ perfectly tuned front port, providing superior and accurate extended low-end response. And because the port is on the front baffle, the D8’s can be positioned close to a wall with no fear of the low-end being choked.

The coaxial transducer design of the system incorporates a steep 4th order crossover along with a newly applied DSP aided group delay filter in order to deliver a phase accurate detailed mid-range with unobstructed clarity in that complex 900Hz – 3 kHz range. Guitars, voices, strings, horns, & reverb trails are very clearly and accurately portrayed and any mid-range anomalies in the source material can be easily determined and addressed. Because of our matched transducer output, mid-range mix elements can be positioned in the stereo field without the fear of being misplaced. The D8 represents the next step forward in detailed clarity.

Like the Q Series, the D8 features our Zero-Point Reference™ custom designed coaxial Digitally-Controlled Transducers™ along with internal DSP to provide a matched output curve for every unit. This allows for accurate no-shift imaging. The DSP allowed pin-point accurate adjusting during the voicing process. The voicing was aided by our award-winning Technical Advisory Committee recording engineers that referenced their hit mixes for voicing considerations. The final D8 pre-set voicing curve is optimal for mid-range detail as well as accurate bass placement and low frequency reproduction. With high-quality components, internal DSP, 100w of power, and 106 dB of SPL, the D8s deliver a large trustwrothy crystal clear audio image.

14″ x 10″ x 12″ @ 22 Pounds Each
Internal DSP for Matched Transducer Output and Meticulous Pre-Set Voicing
100 Watts of Power (60w LF | 40w HF)
Pin-Point Accurate Pre-Set Voicing Aided by Award-Winning Recording Engineers
Boundry selection (3 Voicings)
2.5″ Tuned Front Port For Accurate Low-End Extension.
Steep 4th Order L&R Crossover with DSP Compensation for Reduced Mid-Range Distoriion
Coaxial Designed 8” Diameter Polypropylene Woofer
Coaxial Designed 1″ Diameter Silk Tweeter
Electronically Time Corrected
10-Biquads for Factory Applied DSP Driver Correction
10-Biquads for Factory Applied Voicing Considerations
Frequency Response: 44Hz – 20kHz (+ or – 3dB)
Front Ported All Wood MDF Cabinet w/ Small Radius Edges
Limiter & Driver Protection
Driver Magnitude Correction
Power LED
Sensitivity adjustment (Volume Control)
Short Circuit Protection
Thermal Protection
IEC Power Inlet
Power on/off Switch
1.8 meter EMI Power Cord (115v only)
Balanced XLR Input (female)
TRS ¼ Inch Input (female)
